Mercedes Sprinter 906 / Volkswagen Crafter Tubular Rear Door Spare Wheel Carrier

Mercedes Sprinter 906 / Volkswagen Crafter Tubular Rear Door Spare Wheel Carrier

Regular price £340.00
Regular price Sale price £340.00
Sale Sold out
Tax included.


Vehicle Requirements


  • Mercedes Sprinter 906 2006-2018
  • Volkswagen Crafter 2E/2F 2006-2018
  • All van heights (H1, H2, H3)

Both 6x130 (Single) and 6x205mm(Dually) PCDs


All fixings required to install the wheel carrier to the van are supplied. Wheel bolts to fit the wheel to the carrier are not included. (Locking wheel bolts available separately).

Wheel Carriers bolt to the existing hinges on the door and require a single hole drilling in the skin of the door.

This product does NOT require you to modify or change your hinges. These fit all hinge options for this van without modification.

The third fixing point through the door skin is through a structural part of the door. You are not only fixing to the outer skin - but through the inner structure of the door too.

The door does not need removing to fit this product.

Always test fit any bolt-on product before painting. We will not reimburse for painting if the part is not test fitted prior to painting.

All drilled holes will require any bare metal painting to prevent corrosion. We also bond the door skin mount and the door skin which removes the point load off the bolts whilst also sealing up the hole to prevent water ingress.


  • Product weight: 9KG
  • MIG welded using lightweight Mild Steel ERW tube
  • Jig Built
  • Lasercut and CNC formed components
  • Supplied uncoated for you to finish before installation

Additional Information

Wheeliams Wheel Carriers are popular with van users who are looking for a beautifully designed Wheel Carrier with great practical features and offering amazing value for money.

NO MORE 'HINGE MOD' for this product! This wheel carrier now fits regardless of whether you have 180 or 270 degree hinges with no modifications needed. You do NOT need to modify your hinges any more! We are the only company on the market to offer this solution. This wheel carrier has been redesigned from the ground up to be lighter than before, easier to fit than before and more beautiful than before!

This product is now made from round tube to match our rear ladders!

Fitting the spare wheel at the rear of the vehicle keeps the wheel cleaner than when fitted to the underside and makes access to the wheel safer and easier.

The Wheel Carrier swings out with the opening of the rear door without any additional operations.

Our Wheel Carriers are fully compatible with parking sensors, rear van windows and rear wipers.

No need for you to relocate the vehicle licence plate or the vehicle badge.

You gain additional space under the van to fit gas, fuel or water tanks.

Wheeliams Wheel Carriers can be used for wheels too large to fit in the standard under-van cradle.

The Wheel Carriers are carefully designed for each make of vehicle so that they do not obscure number plates or rear lights.

Wheel Carriers are supplied unfinished in bare metal for you to finish as you wish.

Wheels are bolted on to the carrier using standard wheel bolts and we recommend that you use locking wheel nuts (M14x1.5 thread) for extra security. Please note that these are not included with your product.

Do I have Single or Twin rear wheels?

Our Wheel Carriers fit Mercedes Sprinter and VW Crafter Vans from 2008-2017.

They can accept stock or aftermarket wheels and 3.5T (6x130PCD) single rear wheels.


They can accept stock or aftermarket wheels and 5T (6x205PCD) twin rear wheels.

99% of vans are Single Rear Wheels. These include Sprinter 311, 313, 315, 316, 318, 319. The number 3 denotes that the van is a 3.5 Tonne van and has single rear wheels.

The small minority of vans have twin rear wheels. These include Sprinter 513, 516, 518, 519 models. The number 5 denotes that the van is a 5 Tonne van and has twin rear wheels.

Made in Yorkshire

We are always inspired by the wonderful landscape of Yorkshire and here, on the edge the North Yorkshire Moors National Park, the Wheeliams team design and manufacture a great range of innovative Vanlife and Overlanding products.
Using state-of-the-art 3D design software our team carefully develop and test new ideas. These are then manufactured by our skilled in-house production team and, after rigorous quality checks, are shipped all over the world

Lead Time

Wheel carriers are made to order; typically on a 10-day lead time. Following an order, your wheel carrier is added to our production planner and we aim manufacture and ship your order as quickly as possible.
